| 1993 |
|
| Cavity |
Wire Color |
Description |
|
| A |
not used |
|
|
| B |
Brown/White |
Service engine soon indicator feed |
|
| C |
White/Black |
Diagnostic request signal |
|
| D |
White |
Tachometer signal to instrument
cluster |
|
| E |
Dk Blue |
Theft deterrent-fuel enable feed |
|
| F |
Dk Green/White |
A/c request
signal |
|
| G |
Pink |
Power feed from ECM Fuse #5 |
|
H
H |
Lt Blue/Black
Brown |
(Automatic) TCC
switched power feed
(Manual) Power from turn/back-up Fuse #2 to back-up switch |
|
J
J |
Orange/Black
Lt Green |
(Automatic)
Park/neutral feed from transmission position switch
(Manual) Backup lamp feed |
|
|
Tan/Black |
(Automatic) Torque
converter clutch control |
|
|
|
|
|
|
|
|
|
| 1994 |
|
| Cavity |
Wire Color |
Description |
|
| A |
Lt Blue |
(Automatic)
Performance switch indicator control
(Manual) Clutch anticipate signal (V6 VIN S only) |
|
| B |
Brown/White |
Service engine soon indicator feed |
|
| C |
White/Black |
Diagnostic request signal |
|
| D |
White |
Tachometer signal to instrument
cluster |
|
| E |
Dk Blue |
Theft deterrent-fuel enable feed |
|
| F |
Dk Green/White |
A/c request
signal |
|
| G |
Pink |
Power feed from PCM ignition Fuse #5 |
|
H
H |
Lt Blue/Black
Brown |
(Automatic) TCC
switched power feed
(Manual) Power from turn/back-up Fuse #2 to back-up switch |
|
|
|
Orange/Black
Lt Green |
(Automatic)
Park/neutral feed from transmission position switch (V8 VIN P only)
(Manual) Backup lamp feed |
|
| K |
Tan/Black |
(Automatic)
Torque converter clutch control |
|
|
|
|
|
|
|
|
|
| 1995 |
|
| Cavity |
Wire Color |
Description |
|
| A |
Lt Blue, Grey |
(Automatic)
Performance switch indicator control
(Manual) Clutch anticipate signal (V6 VIN S only) |
|
| B |
Brown/White |
Service engine soon indicator feed |
|
| C |
White/Black |
Diagnostic request signal |
|
| D |
White |
Tachometer signal to instrument
cluster |
|
| E |
Dk Blue |
Theft deterrent-fuel enable feed |
|
| F |
Dk Green/White |
A/c request
signal |
|
| G |
Pink |
Power feed from PCM ignition Fuse #5 |
|
H
H |
Lt Blue/Black
Brown |
(Automatic) TCC
switched power feed
(Manual) Power from turn/back-up Fuse #2 to back-up switch |
|
J
J |
Orange/Black
Lt Green |
(Automatic)
Park/neutral feed from transmission position switch (V8 VIN P only)
(Manual) Backup lamp feed |
|
|
|
Purple |
(Automatic)
Torque converter clutch control (V6 VIN K only) |
|
|
|
| 1996-1997 |
|
| Cavity |
Wire Color |
Description |
|
| A |
Grey |
(Manual)
Clutch anticipate signal
(V6 VIN S only-1996, VIN K only-1997) |
|
| B |
Brown/White |
Service engine soon indicator feed |
|
| C |
White/Black |
Diagnostic request signal (V8 VIN P) |
|
| D |
White |
Tachometer signal to instrument
cluster |
|
| E |
Dk Blue |
Theft deterrent-fuel enable feed |
|
| F |
Dk Green/White |
A/c request
signal |
|
| G |
Pink |
Power feed from engine senor Fuse #10 |
|
H
H |
Lt Blue/Black
Brown |
(Automatic) TCC
switched power feed
(Manual) Power feed from engine sensor Fuse #10 |
|
J
J |
Orange/Black
Lt Green |
(Automatic)
Park/neutral feed from transmission range
switch (V8 VIN P only)
(Manual) Backup lamp feed |
|
| K |
Purple |
Output field
service enable |
|
|
|
|
|
