| page
edited 7/7/2013 |
|
|
| 1993 |
|
| Cavity |
Wire Color |
Description |
|
| A |
Purple |
Starter
enable (theft deterrent) relay to starter solenoid feed |
|
| B |
Black/White |
Ground feed to fuel pump relay |
|
|
Empty |
Power feed from ECM BAT (IP fuse #4)
to ECM |
|
| D |
Empty |
|
|
|
|
|
|
|
|
|
|
| 1994 |
|
| Cavity |
Wire Color |
Description |
|
| A |
Purple |
Theft deterrent relay
to starter solenoid feed |
|
| B |
Black/White |
Ground feed to fuel pump relay |
|
| C |
Orange |
Power feed from PCM BAT fuse to PCM |
|
|
|
Grey |
Feed from fuel
pump and fuel pump relay to prime connector |
|
|
|
|
|
|
|
|
|
| 1995 |
|
| Cavity |
Wire Color |
Description |
|
| A |
Purple |
Theft deterrent relay
to starter solenoid feed |
|
| B |
Black/White |
Ground feed to fuel pump relay |
|
| C |
|
info not known (empty?) |
|
|
Grey |
Feed from fuel
pump and fuel pump relay to prime connector |
|
|
|
| 1996-1997 |
|
| Cavity |
Wire Color |
Description |
|
| A |
Purple |
Theft deterrent relay
to starter solenoid feed |
|
| B |
Black/White |
Ground feed to fuel pump relay |
|
| C |
Orange |
Power feed from PCM BAT fuse to PCM |
|
| D |
Red |
Feed from fuel
pump and fuel pump relay to prime connector |
|
|
|
|
|
